1 Mil Polyimide Discs
Need Help Finding the Right Part?
Masking Product Finder - Get the right size!
Cross Reference Tool - Find equivalent CFS parts!
These discs/dots are manufactured from commercial grade polyimide film with a special silicone adhesive. The polyimide carrier is only 1 Mil, making this tape extremely conformable for irregular shapes and surfaces. Designed for high temperature masking found in conformal coating of PCBs, protection of gold fingers during circuit board soldering and electrical insulation of high temperature coils, motors and transformers.
Product Features
- Temperature Rating: 500° F / 260° C
- All die cuts 3/8" or larger come standard with a split-back liner. Split liner for smaller dimensions upon request
- Meets Class H Requirements, flame retardant
- Excellent dielectric strength and chemical resistance
- Conformable for uneven surfaces or irregular shapes
- Removes cleanly even after long bake cycles with no residue
- Used in Powder Coating, E-Coating, Wave Soldering, Hot Air Leveling, and Circuit Board Insulation
- Standard die cut sizes in stock or can be made to your specifications
Construction
- 1 Mil Polyimide Carrier
- 1.5 Mil Silicone Adhesive
- 2.5 Mil Total Thickness
Specifications
- Tensile Strength (lb/in) - 30
- Elongation (%) - 50
- Steel Adhesion (oz/in) - 25
- Dielectric Strength - 6.5
Polyimide is also known by the trade name Kapton™. If you require the trademarked brand, please inquire with your CFS representaive on pricing.
CFS services many different non-masking customers and industries. From custom die cut thermal pads for LED lighting manufacturers to FDA grade silicone molded parts for medical OEMs - what we can produce from flexible materials is limited only by your imagination.
