High Temp PET Film + Crepe Hot Air Leveling Tape

Sku:HALC
Rolls

Need Help Finding the Right Part?

Masking Product Finder - Get the right size!

Cross Reference Tool - Find equivalent CFS parts!

Product Details
chevron-up

Applied to mask gold fingers, tab areas and other sections of printed circuit boards (PBCs) during the hot air leveling process. The silicone adhesive is specially formulated to hold down and protect the gold fingers during rigorous HAL operations yet remove cleanly from the board without splitting or leaving adhesive residue. A proven mask in double wrap applications. This is a slightly thinner version of our HALR tape.

Product Features

  • Temperature Rating: 480° F/ 250° C in 5 seconds
  • Prevents plating solution undercutting
  • Stands up to multiple operating cycles
  • Reduces rework
  • Excellent temperature and chemical resistance
  • No adhesive residue even after long delay in removal after wave soldering

Construction

  • 1 Mil Polyester Film
  • 6 Mil Crepe Paper
  • 10 Mil Total Thickness
  • Roll Length - 36 yards

Specifications

  • Tensile Strength (lb/in) - 45
  • Elongation (%) - 10
  • Steel Adhesion (oz/in) - 45
