Red High Temp + Crepe Hot Air Leveling Tape

Sku:HALR
Starting at: $5.9200
Starting at: $5.9200
Rolls

Need Help Finding the Right Part?

Masking Product Finder - Use our tool to find the right size.

Cross Reference Tool - Find equivalent CFS products.

Product Details
chevron-up

Applied to mask gold fingers, tab areas and other sections of printed circuit boards (PBCs) during the hot air leveling process. The silicone adhesive is specially formulated to hold down and protect the gold fingers during rigorous HAL operations yet remove cleanly from the board without splitting or leaving adhesive residue. A proven mask in double wrap applications.

Product Features

  • Temperature Rating: 480° F/ 250° C in 5 seconds
  • Prevents plating solution undercutting
  • Stands up to multiple operating cycles
  • Reduces rework
  • Excellent temperature and chemical resistance
  • No adhesive residue even after long delay in removal after wave soldering

Construction

  • 1 Mil Polyester Film
  • 6 Mil Crepe Paper
  • 11 Mil Total Thickness
  • Roll Length - 36 yards

Specifications

  • Tensile Strength (lb/in) - 56
  • Elongation (%) - 5
  • Steel Adhesion (oz/in) - 53
Material Specifications
chevron-up
Available Dimensions chevron-up
Convert Units:








Need a Custom Size?

If you don’t see the dimension you need, let us know. We can create a custom part for you.

Request a Quote
